Conducts comprehensive research by orchestrating web searches, extracting information with LLM, verifying completeness with Prolog logic, and generating citation-backed reports.

% LLM extracts topic overview from search results
understand_topic(SearchResults, Topic, Overview) :-
    @("Analyze `SearchResults` for `Topic`.
       Generate a 2-3 sentence `Overview`.").

% LLM crafts targeted search queries
craft_queries(Topic, Overview, Queries) :-
    @("Based on `Topic` and `Overview`,
       generate 3-5 targeted search queries as a list.").

% LLM processes content and structures report
structure_report(AllResults, Topic, Structure, Sources) :-
    @("Analyze `AllResults`. If sufficient, generate
       `Structure` (outline) and `Sources` (URLs).").

agent_main :-
    param("topic", "Research topic", Topic),

    % Initial search and understanding
    tool(web_search(Topic, num=5), InitialResults),
    understand_topic(InitialResults, Topic, Overview),

    % Targeted searches
    craft_queries(Topic, Overview, Queries),
    findall(R, (member(Q, Queries),
                tool(web_search(Q, num=10), R)), Results),

    % Structure and generate report
    structure_report(Results, Topic, Structure, Sources),
    write_report(Structure, Results, Sources, Report),
    write_to_file("research_report.md", Report),

    answer("Research complete! Report saved to research_report.md").

Extracts Sudoku puzzles from images using vision AI, then solves them with Prolog's CLP(FD) constraint solver. Shows hybrid AI-symbolic reasoning.

% Standard CLP(FD) Sudoku solver
parse_sudoku_string_to_prolog(String, List) :-
    @("You are given a string containing a sudoku in the format `[[5,3,0,0,7,0,0,0,0], [6,0,0,1,9,5,0,0,0], ...]`,
    please parse this into a valid prolog list term and output it in the List variable.
    Do not use 0 for blank fields, instead use an underscore to denote a blank field.").

format_solved_grid(SolvedGrid, MarkdownGrid) :-
    @("Take the `SolvedGrid`, which is a list of lists of numbers (1-9), and format it into a clean,
    human-readable markdown table representing the Sudoku board. Add separators for the 3x3 blocks.
    The output `MarkdownGrid` should be a single markdown string.").

% Sudoku solver using Constraint Logic Programming over Finite Domains (CLP(FD))
% This is a standard, well-known Prolog implementation for solving Sudoku.
sudoku(Rows) :-
    % Ensure the grid is 9x9
    length(Rows, 9),
    maplist(same_length(Rows), Rows),
    % Flatten the grid into a single list of variables
    append(Rows, Vs),
    % The domain for each variable is 1 to 9
    Vs ins 1..9,
    % All numbers in each row must be unique
    maplist(all_distinct, Rows),
    % Transpose the grid to get columns, and ensure they are also unique
    transpose(Rows, Columns),
    maplist(all_distinct, Columns),
    % Define the 3x3 blocks and ensure they are unique
    Rows = [A,B,C,D,E,F,G,H,I],
    blocks(A, B, C),
    blocks(D, E, F),
    blocks(G, H, I),
    % Find a valid assignment of numbers to the variables
    maplist(labeling([ff]), Rows).

% Helper for the solver: defines the 3x3 block constraint
blocks([], [], []).
blocks([N1,N2,N3|Ns1], [N4,N5,N6|Ns2], [N7,N8,N9|Ns3]) :-
    all_distinct([N1,N2,N3,N4,N5,N6,N7,N8,N9]),
    blocks(Ns1, Ns2, Ns3).

% Main agent logic

% Branch 1: Successful image recognition and solving
agent_main :-
    param("image_path:file", "The path to the image file containing the Sudoku puzzle.", ImagePath),
    ( ImagePath \= "" -> true ; (log(error="The 'image_path' parameter is missing."), fail) ),
    log(task="Attempting to solve Sudoku directly from the image: '{ImagePath}'."),

    % Step 1: Use the visualizer tool to perform OCR and extract the grid
    log(task="Analyzing image to extract the puzzle grid and numbers."),
    tool(visualizer(ImagePath,"Identify the Sudoku grid. Perform
            Optical Character Recognition (OCR) on each cell.
            Represent the grid as a Prolog list of lists, where each inner list is a row.
            Use the integer 0 to represent empty cells. The output `SudokuGrid` must be in this
            format, for example: `[[5,3,0,0,7,0,0,0,0], [6,0,0,1,9,5,0,0,0], ...]`.
            If a valid 9x9 grid cannot be reliably extracted, then output nothing"), ToolOutput),

    parse_sudoku_string_to_prolog(ToolOutput, UnsolvedGrid),
    ( UnsolvedGrid \= [] ->
         log(task="Successfully extracted the grid from the image.")\
    ;
        (log(error="Could not recognize a valid Sudoku grid in the image."), fail)
    ),

    yield("Grid = {UnsolvedGrid}"),

    % Step 2: Solve the puzzle using the CLP(FD) solver
    log(task="Solving the puzzle..."),
    sudoku(UnsolvedGrid), % This predicate solves the grid by unifying the variables
    log(task="Puzzle solved successfully."),

    % Step 3: Format the solved grid into a markdown table
    log(task="Formatting the solution for display."),
    format_solved_grid(UnsolvedGrid, SolvedGridMarkdown),

    end_thinking,
    system("You are a helpful assistant that has just solved a Sudoku puzzle from an image for the user."),
    observation("I have successfully analyzed the image, extracted the puzzle, and found the solution."),
    observation(SolvedGridMarkdown),
    chat("Please give me the solution to this Sudoku.").
